Expanded PTFE Tape

No.LL-GST-02

Expanded PTFE Tape is a type of sealing tape made of 100% pure polytetrafluoroethylene with a unidirectional or bidirectional stretched structure. It boasts excellent properties, including self-lubrication, low friction coefficient, chemical corrosion resistance, high temperature and pressure resistance, cold flow resistance, and creep resistance, making it suitable for almost any sealing surface. It is mainly used for the sealing of flanges, pipelines, hydraulic and pneumatic systems, etc., and is applicable to various industries such as the chemical industry, food industry, engineering industry, and pharmaceutical industry.

Description

Core Features

100% Virgin ePTFE: Produced by expanding 100% virgin PTFE into a highly fibrillated structure that is soft, flexible, and exceptionally strong.
Convenient Self-Adhesive Backing: Features a high-quality adhesive strip on one side, allowing for easy "peel-and-stick" installation even on vertical or overhead flange surfaces.
Exceptional Conformability: The marshmallow-like texture allows the tape to compress into a thin, wide ribbon that fills every pit, scratch, and irregularity on the flange face.
Universal Chemical Resistance: Chemically inert across the entire pH range of 0-14, making it safe for use with aggressive acids, alkalis, and solvents (except molten alkali metals).

Technical Advantages

No Waste & Cost-Effective: Unlike sheet gaskets, there is no "middle waste" when using tape. You only use exactly what you need, making it much more economical for large-diameter flanges.
Low Bolt Torque Required: Ideal for fragile or large-diameter equipment where high clamping forces cannot be applied, such as glass-lined vessels or plastic ducting.
Superior Creep Resistance: The expanded fiber structure eliminates cold flow and creep, ensuring long-term seal integrity without the need for constant re-tightening.
Extreme Temperature Stability: Operates reliably from cryogenic $-240^\circ\text{C}$ to $+260^\circ\text{C}$ $+260^\circ\text{C}$

Common Applications

Large Diameter Flanges: Sealing for massive heat exchangers, tank covers, and manways where cutting a sheet gasket is impractical or too expensive.
Fragile Equipment: The perfect seal for glass-lined reactors, fiberglass (FRP) piping, and plastic tanks.
Irregular Shapes: Easily follows the contours of non-standard flanges, pump housings, and compressor split-cases.
HVAC & Ducting: Providing a high-temperature, chemically resistant seal for industrial ventilation and exhaust systems.
